FRP (Fibre Reinforced Plastic) - Technology
Project Name : WESTERN COURT ANNEXE, JANPATH, NEW DELHI
Western Court Annexe has site area of 7.72 acres with built up area of 9220 sqm with two level basements. It is grade II heritage building. The House Committee under the Chairmanship of Shri Arjun Ram Meghwal, MP the then Chairperson House Committee decided to construct the Western court Annexe with additional 88 suites as transit accommodation to the newly elected Members of Parliament.
700 Lakh
Project Budget
05 Dec 2016
Start Date
04 Apr 2018
Completion Date
NEW DELHI
Location
Project Team / Contact Us
| S.No. | Name(Mr/Mrs) | Designation | Office Address | Office Number | Mobile Number | Email ID |
|---|---|---|---|---|---|---|
| 1 | Jayesh Kumar | ADG (NDR) | ||||
| 2 | Dr. Sonia Mehta | Chief Architect | ||||
| 3 | Rajiv Singhal | CPM |
MATERIAL
Name
FRP (Fibre Reinforced Plastic)
Description
In Wesern Court Annexe project combination of FRP and GRC are used for Cornices and Jali respectively to ease out the construction in time frame. This helped in speedy construction at the time of execution.
FRP cornice mouldings have become one of the most popular use of fiberglass. Not only for its ease of use, but fiberglass cornice can be manufactured to replicate most finishes including cast iron, terra cotta, limestone, sandstone, marble, granite, copper, steel, wood, sheet metal and other popular building materials. Finishes can range from a smooth, dull, matte to a high gloss polished look, or a slight texture to a rough stone texture.
FRP cornice is very practical when compared with the material, maintenance, and installation cost of other traditional materials. One should not assume that the material cost of fiberglass is low, but the installation methods and procedures allow for lower installed costs and lower life cycle costs.
Advantages of GRC jail overweigh conventional concrete jail. GRC is modern day product. It is light weight and available in wide range of innovative designs.
Major Gains
Over and above all the above mentioned characteristics these helped in speedy construction at the time of execution. The Project completed before expected time.
Implementation Strategy
| S.No. | Description | Images | |
|---|---|---|---|
| 1 | Architectural planning:
Structural planning:
Other services:
Site implementation-
|
|
